Drawing version
Provide revision number or issue date so everyone quotes from the same file.
Custom sheet metal
Custom sheet metal sourcing
Send a drawing for quotation review. Mechivon coordinates the enquiry with independent suppliers; manufacturing capability and quotation details are checked per project.
Material & thickness
Name grade/standard and thickness; identify substitutions that are not acceptable.
Quantity & destination
Give prototype and production quantities, delivery destination and packaging needs.
Tolerances
Call out critical dimensions and general tolerances, including hole positions.
Surface treatment
Specify coating, finish, colour, inspection and documentation requirements.
Purpose
Describe use, expected service conditions, assembly interfaces or special controls.
Example drawing only; it is provided to show drawing requirements and does not represent a completed customer project. Actual production orders must use the customer-approved drawing.
Submit sheet metal enquiry
Attach a drawing and project details.
Send what you have; we will help clarify missing details before quotation. You receive a reference number and summary.
